- CPU
- Intel® Socket LGA1700 for Intel® Core™ 14th & 13th Gen Processors, Intel® Core™ 12th Gen, Pentium® Gold and Celeron® Processors
- Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**
- * Refer to www.asus.com for CPU support list.
- ** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.
- Chipset
- Intel® B760 Chipset
- Memory
- 4 x DIMM slots, Max. 192GB, DDR5
- 7800+(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800MHz Non-ECC, Un-buffered Memory*
- Dual Channel Memory Architecture
- Supports Intel® Extreme Memory Profile
- (XMP)
- OptiMem II
- * Supported memory types, data rate(Speed),
- and number of DRAM module vary depending on the CPU and memory configuration,
- for more information refer to www.asus.com for memory support list.
- * Refer to www.asus.com for the Memory QVL
- (Qualified Vendors Lists).
- Graphics
- 1 x DisplayPort**
- 1 x HDMI®***
- * Graphics specifications may vary between
- CPU types. Please refer to www.intel.com for any updates.
- ** Support 4K@60Hz as specified in
- DisplayPort 1.4
- *** Support 4K@60Hz as specified in HDMI
- 2.1.
- Expansion Slots
- Intel® 13th & 12th Gen Processors
- 1 x PCIe 5.0 x16 slot(s)
- Intel® B760 Chipset
- 1 x PCIe 4.0 x16 slot (supports x4 mode)
- 2x PCIe 4.0 x1 slots
- - To ensure compatibility of the device
- installed, please refer to https://www.asus.com/support/ for the list of
- supported peripherals.
- Storage
- Total supports 2 x M.2 slots and 4 x SATA
- 6Gb/s ports*
- Intel® 13th & 12th Gen Processors
- M.2_1 slot (Key M), type 2242/2260/2280
- (supports PCIe 4.0 x4 mode)
- Intel® B760 Chipset**
- M.2_2 slot (Key M), type 2242/2260/2280
- (supports PCIe 4.0 x4 mode)
- 4 x SATA 6Gb/s ports
- * Intel® Rapid Storage Technology supports
- SATA RAID 0/1/5/10.
- Ethernet
- 1 x Intel® 2.5Gb Ethernet
- ASUS LANGuard
- Wireless & Bluetooth
- Wi-Fi 6E
- 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
- Supports 2.4/5/6GHz frequency band*
- Bluetooth® v5.3
- * WiFi 6E 6GHz regulatory may vary between
- countries.
- USB
- Rear USB (Total 9 ports)
- 1 x USB 3.2 Gen 2x2 port(s) (1 x USB
- Type-C®)
- 1 x USB 3.2 Gen 2 port(s) (1 x Type-A)
- 3x USB 3.2 Gen 1 port(s) (2 x Type-A, 1 x
- USB Type-C®)
- 4 x USB 2.0 port(s) (4 x Type-A)
- Front USB (Total 7 ports)
- 1 x USB 3.2 Gen 2 connector (supports USB
- Type-C®)
- 1 x USB 3.2 Gen 1 header supports
- additional 2 USB 3.2 Gen 1 ports
- 2 x USB 2.0 header supports additional 4
- USB 2.0 ports
- Audio
- ROG SupremeFX 7.1-Channel High
- Definition Audio CODEC S1220A
- - Impedance sense for front and rear
- headphone outputs
- - Supports: Jack-detection,
- Multi-streaming, Front Panel Jack-retasking
- - High quality 120 dB SNR stereo playback
- output and 113 dB SNR recording input (Line-in)
- - Supports up to 32-Bit/192 kHz playback*
- Audio Features
- - SupremeFX Shielding Technology
- - Savitech SV3H712 AMP
- - Premium audio capacitors
- - Audio cover
- * Due to limitations in HAD bandwidth,
- 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.
- Back Panel I/O Ports
- 1 x USB 3.2 Gen 2x2 port(s) (1 x USB
- Type-C®)
- 1 x USB 3.2 Gen 2 port(s) (1 x Type-A)
- 3x USB 3.2 Gen 1 port(s) (2 x Type-A, 1 x
- USB Type-C®)
- 4 x USB 2.0 port(s) (4 x Type-A)
- 1 x HDMI® port
- 1 x DisplayPort
- 1 x Wi-Fi Module
- 1 x Intel® 2.5Gb Ethernet
- 5 x Audio jacks
- 1 x BIOS FlashBack™ button
- Internal I/O Connectors
- Fan and Cooling related
- 1 x 4-pin CPU Fan header
- 1 x 4-pin CPU OPT Fan header
- 1 x 4-pin AIO Pump header
- 2 x 4-pin Chassis Fan header(s)
- Power related
- 1 x 24-pin Main Power connector
- 1 x 8-pin +12V Power connector
- 1 x 4-pin +12V Power connector
- Storage related
- 2 x M.2 slots (Key M)
- 4 x SATA 6Gb/s ports
- USB
- 1 x USB 3.2 Gen 2 connector (supports USB
- Type-C®)
- 1 x USB 3.2 Gen 1 header supports
- additional 2 USB 3.2 Gen 1 ports
- 2 x USB 2.0 headers support additional 4
- USB 2.0 ports
- Miscellaneous
- 3 x Addressable Gen 2 header(s)
- 1 x AURA RGB header(s)
- 1 x Clear CMOS header
- 1 x Front Panel Audio header (AAFP)
- 1 x S/PDIF Out header
- 1 x 20-3 pin System Panel header with
- Chassis intrude function
- 1 x Thermal Sensor header
- 1 x Thunderbolt™ (USB4®) header
- Special Features
- Extreme Engine Digi+
- - 5K Black Metallic Capacitors
- ASUS Q-Design
- - M.2 Q-Latch
- - PCIe Slot Q-Release
- - Q-DIMM
- - Q-LED (CPU [red], DRAM [yellow], VGA
- [white], Boot Device [yellow green])
- - Q-Slot
- ASUS Thermal Solution
- - M.2 heatsink
- ASUS EZ DIY
- - BIOS FlashBack™ button
- - BIOS FlashBack™ LED
- -CPU
- Socket lever protector
- - ProCool
- - Pre-mounted I/O shield
- - SafeSlot
- - SafeDIMM
- AURA Sync
- - Aura RGB header
- - Addressable Gen 2 header
- Software Features
- ROG Exclusive Software
- - GameFirst VI
- - ROG CPU-Z
- - Sonic Studio III + Sonic Studio Virtual
- Mixer + Sonic Suite Companion
- - Sonic Radar III
- - DTS® Sound Unbound
- ASUS Exclusive Software
- Armoury Crate
- - AIDA64 Extreme (60 days free trial)
- - AURA Creator
- - AURA Sync
- - Fan Xpert 4
- - Two-Way AI Noise Cancelation
- - Power Saving
- AI Suite 3
- - Performance And Power Saving Utility
- - DIGI+ VRM
- - PC Cleaner
- MyAsus
- Norton 360 for Gamers (60 days free trial)
- WinRAR
- UEFI BIOS
- ASUS EZ DIY
- - ASUS CrashFree BIOS 3
- - ASUS EZ Flash 3
- - ASUS UEFI BIOS EZ Mode
- MemTest86
- BIOS
- 256 Mb Flash ROM, UEFI AMI BIOS
- Manageability
- WOL by PME, PXE
- Accessories
- Cables
- 2 x SATA 6Gb/s cables
- Additional Cooling Kit
- 1 x Thermal pad for M.2
- Miscellaneous
- 1 x ASUS Wi-Fi moving antennas
- 1 x Cable ties pack
- 1 x Rubber Package(s) for M.2
- 1 x Q-Latch package(s) for M.2
- 1 x ROG key chain
- 1 x ROG Strix stickers
- 1 x ROG Strix thank you card
- Documentation
- 1 x User manual
- Operating System
- Windows® 11, Windows® 10 64-bit
- Form Factor
- 9.6 inch x 9.6 inch (24.4 cm x 24.4 cm)
