Kingston’s UV500 SSD dramatically improves your system’s responsiveness with incredible boot, loading, and transfer times compared to mechanical hard drives. It uses a Marvell 88SS1074 controller and 3D NAND Flash to power through daily tasks and improve productivity. Perfect for your desktops, small form factor pc and laptops.
Available in multiple form factors and capacities from 120GB–1.92TB1 giving you options to meet your system’s needs. End-to-end data protection using 256-bit AES Hardware-based encryption and support for TCG Opal 2.0 security management solutions allows the usage of independent software vendors such as Symantec, McAfee, WinMagic and others. Kingston’s UV500 family of encrypted solid-state drives dramatically improves the responsiveness of your existing system or client upgrades with incredible boot, loading, and transfer times compared to mechanical hard drives.
Powerful Powered by a Marvell 88SS1074 controller combined with Next Gen 64-layer 3D TLC NAND Flash for read and write speeds up to 520MB/s and 500MB/s2 , this SSD is 10X faster than a traditional hard drive for better performance, ultra-responsive multi-tasking, and an overall faster system. It is also cooler, quieter, and its shock and vibration resistance makes it ideal for notebooks, small form factor PCs, and other mobile computing devices. Encrypted SSD UV500 provides end-to-end data protection using the advanced 256-bit AES Hardware-based encryption and support for Trusted Computing Group (TCG) Opal 2.0 as required by security platforms.
Enables the advantage of drive encryption and Data Loss Prevention (DLP) software programs to activate and manage TCG Opal, such as Symantec, McAfee, WinMagic and others. Serves as an important element to security policies when complying with industry standards and global regulations, such as the General Data Protection Regulation (GDPR)3 . System Solution Available in multiple capacities from 120GB–1.92TB1 provides efficient client upgrades, Windows 10 migrations, and advantages for system builders to extend the life of systems. Accelerate as a boot drive, multitasking workloads, or hosting your most frequently used applications.
3D TLC NAND — Increased density is the key to supporting broader workloads, ultra-responsive multi-tasking, and an overall faster system.
> Encrypted protection — Protect sensitive data with support for 256-bit AES Hardware-based Encryption and TCG Opal 2.0 making it GDPR ready3 .
> Ideal for desktops, small form factor PCs, and notebooks — Comes in multiple form factors (2.5”/M.2/mSATA) to fit in a wider array of systems. It is ideal for slimmer notebooks and systems with limited space.
> Multiple capacities — Available in a range of capacities up to 1.92TB1 to meet your data storage requirements. SPECIFICATIONS > Form factor 2.5"/M.2 2280/mSATA > Interface SATA Rev. 3.0 (6Gb/s) – with backwards compatibility to SATA Rev. 2.0 (3Gb/s) > Capacities1 120GB, 240GB, 480GB, 960GB, 1.92TB
> Controller Marvell 88SS1074
> NAND 3D TLC
> Encryption Encryption Support (AES 256-bit)
> Sequential Read/Write2 120GB — up to 520/320MB/s 240GB — up to 520/500MB/s 480GB — up to 520/500MB/s 960GB — up to 520/500MB/s 1.92TB — up to 520/500MB/s
> Maximum 4K Read/Write2 120GB — up to 79,000/18,000 IOPS 240GB — up to 79,000/25,000 IOPS 480GB — up to 79,000/35,000 IOPS 960GB — up to 79,000/45,000 IOPS 1.92TB — up to 79,000/50,000 IOPS
> Power Consumption 0.195W Idle / 0.5W Avg / 1.17W (MAX) Read / 2.32 W (MAX) Write
> Dimensions 100.1mm x 69.85mm x 7mm (2.5") 80mm x 22mm x 3.5mm (M.2) 50.8mm x 29.85mm x 4.85mm (mSATA)
> Operating temperature 0°C~70°C
> Storage temperature -40°C~85°C
> Weight 120GB–480GB — 41g (2.5") 960GB — 57g (2.5") 1.92TB — 52g (2.5") 120GB — 6.6g (M.2) 240GB — 6.7g (M.2) 480GB — 7.7g (M.2) 960GB — 7.8g (M.2) 120GB — 6.2g (mSATA) 240GB–480GB — 6.7g (mSATA)
> Vibration operating 2.17G Peak (7–800Hz)
> Vibration non-operating 20G Peak (10–2000Hz)
> Life expectancy 1 million hours MTBF
> Warranty/support4 limited 5-year warranty with free technical support
> Total Bytes Written (TBW)5 120GB — 60TB 240GB — 100TB 480GB — 200TB 960GB — 480TB 1.92TB — 800TB
